NEC NP-PA1705UL-B data projector Standard throw projector 17000 ANSI lumens LCD WUXGA (1920x1200) Black1
NEC NP-PA1705UL-B data projector Standard throw projector 17000 ANSI lumens LCD WUXGA (1920x1200) Black1 NEC NP-PA1705UL-B data projector Standard throw projector 17000 ANSI lumens LCD WUXGA (1920x1200) Black2 NEC NP-PA1705UL-B data projector Standard throw projector 17000 ANSI lumens LCD WUXGA (1920x1200) Black3 NEC NP-PA1705UL-B data projector Standard throw projector 17000 ANSI lumens LCD WUXGA (1920x1200) Black4 NEC NP-PA1705UL-B data projector Standard throw projector 17000 ANSI lumens LCD WUXGA (1920x1200) Black5 NEC NP-PA1705UL-B data projector Standard throw projector 17000 ANSI lumens LCD WUXGA (1920x1200) Black6 NEC NP-PA1705UL-B data projector Standard throw projector 17000 ANSI lumens LCD WUXGA (1920x1200) Black7 NEC NP-PA1705UL-B data projector Standard throw projector 17000 ANSI lumens LCD WUXGA (1920x1200) Black8

NEC NP-PA1705UL-B data projector Standard throw projector 17000 ANSI lumens LCD WUXGA (1920x1200) Black

NEC NP-PA1705UL-B. Projector brightness: 17000 ANSI lumens, Projection technology: LCD, Projector native resolution: WUXGA (1920x1200). Light source type: Laser, Service life of light source: 20000 h. Focus: Motorized, Horizontal lens shift range: -25 - 25%, Vertical lens shift range: -65 - 65%. Analog signal format system: NTSC, PAL, NTSC 4.43, PAL 60, PAL M, PAL N, SECAM, Supported graphics resolutions: 1280 x 1024 (SXGA), 3840 x 2160, 800 x 600 (SVGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1024 x..., Supported video modes: 1080i, 480i, 1080p, 480p, 720p, 576i, 576p. Serial interface type: RS-232, HDMI version: 2.2/1.4
Manufacturers: NEC DISPLAY SOLUTIONS , NEC
SKU: 7661004
Manufacturer part number: NP-PA1705UL-B
UPC: 0805736078527
MSRP: $29,999.00
$26,031.00
17,000-Lumen Professional Installation Projector w/ 4K support

NEC's PA1705UL-B (black cabinet) is a 16,000-lumen (Center: 17,000lm) LCD laser projector with advanced professional installation features for higher education and corporate users. With its multitude of digital inputs, connection to any computer or high definition device is possible. Enjoy design and installation flexibility with a complete line of optional motorized lenses (lens shift, focus and zoom), roll free installation capabilities. The HDBaseT input provides a single connection for uncompressed full HD digital video, audio, ethernet power and various control signals. HDBaseT Repeater allows cascading of the signal for edge-blending or stacking applications.
- 4K Ready - Display stunning 4K 60P content using NEC’s proprietary high performance video processing/scaling chip from “Ultra HD Blu-ray” and “4K TV broadcasting” without the loss of critical details.
- Learning of basic control of competitors product reducing the need for reprogramming of a control system. (call NEC for complete list)
- Integrated software applications such as AMX Beacon, Crestron Roomview, Extron XTP and PJ link allow for complete interactivity and control.
- 16,000-lumen (Center: 17,000lm) brightness provides brilliant images in most high ambient lighting situations.
- ProAssist is software for controlling the projector and adjusting the projected image on the screen from a computer via a network. It allows necessary adjustments to be carried out easily when combining several projectors together to project a large screen in a classroom, meeting room, auditorium or other large space.
17,000-Lumen Professional Installation Projector w/ 4K support

NEC's PA1705UL-B (black cabinet) is a 16,000-lumen (Center: 17,000lm) LCD laser projector with advanced professional installation features for higher education and corporate users. With its multitude of digital inputs, connection to any computer or high definition device is possible. Enjoy design and installation flexibility with a complete line of optional motorized lenses (lens shift, focus and zoom), roll free installation capabilities. The HDBaseT input provides a single connection for uncompressed full HD digital video, audio, ethernet power and various control signals. HDBaseT Repeater allows cascading of the signal for edge-blending or stacking applications.
- 4K Ready - Display stunning 4K 60P content using NEC’s proprietary high performance video processing/scaling chip from “Ultra HD Blu-ray” and “4K TV broadcasting” without the loss of critical details.
- Learning of basic control of competitors product reducing the need for reprogramming of a control system. (call NEC for complete list)
- Integrated software applications such as AMX Beacon, Crestron Roomview, Extron XTP and PJ link allow for complete interactivity and control.
- 16,000-lumen (Center: 17,000lm) brightness provides brilliant images in most high ambient lighting situations.
- ProAssist is software for controlling the projector and adjusting the projected image on the screen from a computer via a network. It allows necessary adjustments to be carried out easily when combining several projectors together to project a large screen in a classroom, meeting room, auditorium or other large space.
Products specifications
Attribute nameAttribute value
Width23.6"
Depth19.3"
Height9.37"
Weight63.7 lbs
Power SourceAC
Current12.8 A
Projection Distance42.9 - 1692.9"
Full HDYes
Handheld remote controlYes
Native aspect ratio16:10
Power consumption (standby)0.15 W
HDMI version2.2/1.4
Supported video modes1080i, 480i, 1080p, 480p, 720p, 576i, 576p
Contrast ratio (typical)3000000:1
PC Audio outYes
Zoom capabilityYes
Analog signal format systemNTSC, PAL, NTSC 4.43, PAL 60, PAL M, PAL N, SECAM
Projector brightness17000 ANSI lumens
Projection technologyLCD
Projector native resolutionWUXGA (1920x1200)
Keystone correction, vertical-30 - 30 °
Service life of light source20000 h
Projector brightness (economic mode)15300 ANSI lumens
Keystone correction, horizontal-40 - 40 °
Horizontal lens shift range-25 - 25 %
Vertical lens shift range-65 - 65 %
HDBaseT portYes
Horizontal synchronization (min)24 kHz
Horizontal synchronization (max)153 kHz
Vertical synchronization (min)50 kHz
Vertical synchronization (max)120 kHz
3G-SDI input1
Design
CertificationUSA UL60950-1: 2nd edition, FCC Part15 Subpart B(ANSI C63.4.2014), CAN/CSA C22.2 No.62368-1-18,3rd Edition, ICES-003 Issue 7(ANSI C63.4-2014)
Technical details
Product colorBlack
Screen size compatibility60 - 500"
Serial interface typeRS-232
Features
Noise level43 dB
Product typeStandard throw projector
Supported graphics resolutions1280 x 1024 (SXGA), 3840 x 2160, 800 x 600 (SVGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1024 x 768 (XGA), 640 x 480 (VGA), 1920 x 1200 (WUXGA)
Packaging data
Package width29.1"
Package depth24.8"
Package height15"
Package weight71.9 lbs
Packaging content
ManualYes
Performance
Ethernet LANYes
Ports & interfaces
Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity1
HDMI ports quantity2
Power
Power consumption (typical)1035 W
AC input frequency50/60 Hz
AC input voltage100-240 V
Operational conditions
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)20 - 80 %
Storage relative humidity (H-H)20 - 80 %
Operating altitude0 - 472440.9"
Light source
Light source typeLaser
Focusing
FocusMotorized
*
*
*
Products specifications
Attribute nameAttribute value
Width23.6"
Depth19.3"
Height9.37"
Weight63.7 lbs
Power SourceAC
Current12.8 A
Projection Distance42.9 - 1692.9"
Full HDYes
Handheld remote controlYes
Native aspect ratio16:10
Power consumption (standby)0.15 W
HDMI version2.2/1.4
Supported video modes1080i, 480i, 1080p, 480p, 720p, 576i, 576p
Contrast ratio (typical)3000000:1
PC Audio outYes
Zoom capabilityYes
Analog signal format systemNTSC, PAL, NTSC 4.43, PAL 60, PAL M, PAL N, SECAM
Projector brightness17000 ANSI lumens
Projection technologyLCD
Projector native resolutionWUXGA (1920x1200)
Keystone correction, vertical-30 - 30 °
Service life of light source20000 h
Projector brightness (economic mode)15300 ANSI lumens
Keystone correction, horizontal-40 - 40 °
Horizontal lens shift range-25 - 25 %
Vertical lens shift range-65 - 65 %
HDBaseT portYes
Horizontal synchronization (min)24 kHz
Horizontal synchronization (max)153 kHz
Vertical synchronization (min)50 kHz
Vertical synchronization (max)120 kHz
3G-SDI input1
Design
CertificationUSA UL60950-1: 2nd edition, FCC Part15 Subpart B(ANSI C63.4.2014), CAN/CSA C22.2 No.62368-1-18,3rd Edition, ICES-003 Issue 7(ANSI C63.4-2014)
Technical details
Product colorBlack
Screen size compatibility60 - 500"
Serial interface typeRS-232
Features
Noise level43 dB
Product typeStandard throw projector
Supported graphics resolutions1280 x 1024 (SXGA), 3840 x 2160, 800 x 600 (SVGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1024 x 768 (XGA), 640 x 480 (VGA), 1920 x 1200 (WUXGA)
Packaging data
Package width29.1"
Package depth24.8"
Package height15"
Package weight71.9 lbs
Packaging content
ManualYes
Performance
Ethernet LANYes
Ports & interfaces
Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity1
HDMI ports quantity2
Power
Power consumption (typical)1035 W
AC input frequency50/60 Hz
AC input voltage100-240 V
Operational conditions
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)20 - 80 %
Storage relative humidity (H-H)20 - 80 %
Operating altitude0 - 472440.9"
Light source
Light source typeLaser
Focusing
FocusMotorized
