Trendnet TPE-3102WS network switch Managed 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) Black

Trendnet TPE-3102WS. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 16000 entries, Switching capacity: 80 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE.... Power over Ethernet (PoE). Rack mounting
Manufacturers: Trendnet , TRENDNET INC
SKU: 6852613
Manufacturer part number: TPE-3102WS
UPC: 0710931162448
$334.99
TRENDnet’s Multi-Gigabit Web Smart PoE+ Switch series offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of SMB networks. Each of these rack-mountable IPv6-ready managed switches come with an intuitive web-based interface. Advanced managed switch features include LACP to increase bandwidth between switches by grouping ports together, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making these 2.5G managed PoE+ switches with 10G SFP+ slots powerful solutions for any SMB network. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with an easy-to-use voice VLAN feature.

These multi-gigabit managed PoE+ switches come equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. Each multi-gig managed PoE+ switch also offers two dedicated 10G SFP+ slots for high-speed network connections, providing a cost-effective solution in adding 10G link capability to an SMB network. The switch design lowers energy consumption and eliminates distracting operating noise. TRENDnet’s reliable 2.5G managed PoE+ switches with 10G SFP+ slots offer cost-effective solutions to increase your network’s throughput.

Installers and integrators can save on equipment costs and reduce installation time with TRENDnet’s Multi-Gig Web Smart Managed PoE+ Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables. With PoE technology, users only need one set of cables to deliver both data and power. With these 2.5G managed PoE+ switches, network PoE devices, such as high-power wireless access points, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.



  • 8 x 2.5GBASE-T PoE+ ports
  • 2 x 10G SFP+ slots
  • 240W PoE power budget
  • Backwards compatible with 100/1000BASE-T devices
  • Easy-to-use web-based management interface
  • PoE alive check automatically attempts to recover an unresponsive PoE device connected
  • Supports IPv6, LACP, VLAN, QoS, and IGMP Snooping
  • Bandwidth control per port
  • Private, Multicast, and Voice VLAN support
  • 1U 19” rack mountable
  • 80Gbps switching capacity
  • IEEE 802.3bz (2.5G) compliant
  • IEEE 802.3ae (SFP+) compliant
  • NDAA / TAA compliant (U.S. and Canada only)
TRENDnet’s Multi-Gigabit Web Smart PoE+ Switch series offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of SMB networks. Each of these rack-mountable IPv6-ready managed switches come with an intuitive web-based interface. Advanced managed switch features include LACP to increase bandwidth between switches by grouping ports together, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making these 2.5G managed PoE+ switches with 10G SFP+ slots powerful solutions for any SMB network. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with an easy-to-use voice VLAN feature.

These multi-gigabit managed PoE+ switches come equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. Each multi-gig managed PoE+ switch also offers two dedicated 10G SFP+ slots for high-speed network connections, providing a cost-effective solution in adding 10G link capability to an SMB network. The switch design lowers energy consumption and eliminates distracting operating noise. TRENDnet’s reliable 2.5G managed PoE+ switches with 10G SFP+ slots offer cost-effective solutions to increase your network’s throughput.

Installers and integrators can save on equipment costs and reduce installation time with TRENDnet’s Multi-Gig Web Smart Managed PoE+ Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables. With PoE technology, users only need one set of cables to deliver both data and power. With these 2.5G managed PoE+ switches, network PoE devices, such as high-power wireless access points, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.



  • 8 x 2.5GBASE-T PoE+ ports
  • 2 x 10G SFP+ slots
  • 240W PoE power budget
  • Backwards compatible with 100/1000BASE-T devices
  • Easy-to-use web-based management interface
  • PoE alive check automatically attempts to recover an unresponsive PoE device connected
  • Supports IPv6, LACP, VLAN, QoS, and IGMP Snooping
  • Bandwidth control per port
  • Private, Multicast, and Voice VLAN support
  • 1U 19” rack mountable
  • 80Gbps switching capacity
  • IEEE 802.3bz (2.5G) compliant
  • IEEE 802.3ae (SFP+) compliant
  • NDAA / TAA compliant (U.S. and Canada only)
Products specifications
Attribute nameAttribute value
Width11.8"
Depth9.06"
Height1.73"
Weight5 lbs
Switch TypeManaged
Power SourceAC/PoE
Switching capacity80 Gbit/s
Number of VLANs4094
SFP+ module slots quantity2
Power over Ethernet (PoE) power per port30 W
DHCP featuresDHCP snooping
Link aggregationYes
IGMP snoopingYes
Forwarding rate59.52 Mpps
Design
CertificationCE FCC UL
Technical details
Product colorBlack
Features
Number of fans1 fan(s)
Noise level48.5 dB
Mean time between failures (MTBF)342321 h
Performance
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3x, IEEE 802.3z
Other features
Rack mountingYes
MAC address table16000 entries
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports type2.5G Ethernet (100/1000/2500)
Power
AC input frequency50/60 Hz
AC input voltage100 - 240 V
Power protection featuresOver current, Short circuit
Total Power over Ethernet (PoE) budget240 W
Power consumption (max)60 W
Network
Jumbo frames supportYes
Jumbo frames10000
10G supportYes
VLAN supportYes
Virtual LAN featuresPrivate VLAN, Tagged VLAN, Voice VLAN
Operational conditions
Operating temperature (T-T)0 - 40 °C
Data transmission
Packet buffer memory1.5 MB
Protocols
Management protocolsSNMP v1, v2c, v3
Power over Ethernet (PoE)
Power over Ethernet (PoE)Yes
*
*
*
Products specifications
Attribute nameAttribute value
Width11.8"
Depth9.06"
Height1.73"
Weight5 lbs
Switch TypeManaged
Power SourceAC/PoE
Switching capacity80 Gbit/s
Number of VLANs4094
SFP+ module slots quantity2
Power over Ethernet (PoE) power per port30 W
DHCP featuresDHCP snooping
Link aggregationYes
IGMP snoopingYes
Forwarding rate59.52 Mpps
Design
CertificationCE FCC UL
Technical details
Product colorBlack
Features
Number of fans1 fan(s)
Noise level48.5 dB
Mean time between failures (MTBF)342321 h
Performance
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3x, IEEE 802.3z
Other features
Rack mountingYes
MAC address table16000 entries
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports type2.5G Ethernet (100/1000/2500)
Power
AC input frequency50/60 Hz
AC input voltage100 - 240 V
Power protection featuresOver current, Short circuit
Total Power over Ethernet (PoE) budget240 W
Power consumption (max)60 W
Network
Jumbo frames supportYes
Jumbo frames10000
10G supportYes
VLAN supportYes
Virtual LAN featuresPrivate VLAN, Tagged VLAN, Voice VLAN
Operational conditions
Operating temperature (T-T)0 - 40 °C
Data transmission
Packet buffer memory1.5 MB
Protocols
Management protocolsSNMP v1, v2c, v3
Power over Ethernet (PoE)
Power over Ethernet (PoE)Yes
