Width
|
20.2" |
|
Depth
|
23" |
|
Height
|
10.4" |
|
Weight
|
38.6 lbs |
|
Display
|
LCD |
|
Control type
|
Touch |
|
Cable lock slot
|
Yes |
|
Image formats supported
|
BMP, JPEG, MTIFF, PNG, TIF, TIFF |
|
Scanner type
|
Flatbed scanner |
|
Media types supported
|
ADF: Paper (Plain, Inkjet, Inkjet Brochure/Glossy), Photo Paper; Flatbed: All ADF Media, Envelopes, Labels, Cards, Books |
|
HP segment
|
Business |
|
Pallet dimensions (W x D x H)
|
47.2 x 39.4 x 86.4" |
|
Number of layers per pallet
|
3 pc(s) |
|
Number of cartons per pallet layer
|
5 pc(s) |
|
Maximum duty cycle
|
10000 pages per month |
|
Duplex scanning
|
Yes |
|
Power consumption (PowerSave)
|
1.2 W |
|
Scan to
|
E-mail, Network folder, USB, FTP |
|
Auto document feeder (ADF) input capacity
|
150 sheets |
|
Scan technology
|
CIS/CCD |
|
Power consumption (off)
|
0.3 W |
|
Pallet dimensions (W x D x H) (imperial)
|
47.2 x 39.4 x 86.4" |
|
Harmonized System (HS) code
|
84716070 |
|
UNSPSC-code
|
43211711 |
|
Color scanning
|
Yes |
|
Scan drivers
|
ISIS, TWAIN, WIA |
|
Electromagnetic compatibility
|
CISPR 22:2008 (International) - Class A, CISPR 32:2012 (International) - Class A, EN 55032: 2012 (EU) - Class A, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010, EMC Directive 2014/30/EU; Other EMC approvals as required by individual countries |
|
Scan file formats
|
CSV, HTML, JPG, OCR, PDF, RTF, TIFF, TXT, XPS |
|
Grayscale levels
|
256 |
|
Pallet weight (imperial)
|
672.9 lbs |
|
Recommended operating temperature range (T-T)
|
10 - 35 °C |
|
Control panel
|
XGA 1024x768 LCD |
|
Recommended media weight
|
45 - 199 g/m² |
|
Recommended system requirements
|
2 GB available hard disk space; or 1.3 GB available hard drive space; Internet; For HP Scan; Windows 10; 8.1; 8; 7; 32/64-bit; 2 GB available hard disk space; CD-ROM/DVD drive or Internet connection; USB port; Internet Explorer; 2 GHz processor; 1024 x 768 SVGA monitor.
1.3 GB available hard drive space; Internet. |
|
Box contents
|
HP Digital Sender Flow 8500 fn2 Document Capture; Hardware Install guide; HP 8500 fn2 HbrCD for Mac And PC; HP User's Guide Regulatory Info CD; Power Cord; USB cable |
|
Total carbon footprint (kg of CO2e)
|
770 |
|
Network Ready
|
Yes |
|
Country of Origin
|
China |
|
Certification
|
CISPR 22:2008 (International) - Class A, CISPR 32:2012 (International) - Class A, EN 55032: 2012 (EU) - Class A, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010, EMC Directive 2014/30/EU; Other EMC approvals as required by individual countries |
|
Built-in display
|
Yes |
|
Sustainability certificates
|
ENERGY STAR, EPEAT |
|
Sustainability compliance
|
Yes |
|
Internal memory
|
3584 MB |
|
Power supply type
|
AC |
|
Dimensions (WxDxH)
|
20.2 x 23 x 10.4" |
|
Package width
|
23.6" |
|
Package depth
|
15.6" |
|
Package height
|
28.8" |
|
Package weight
|
44.8 lbs |
|
Bundled software
|
HP browser, Mac OS Welcome Screen (Directs users to HP.com or OS App Source for printer software), Online user manuals. Download from hp.com Network TWAIN (32-bit and 64-bit), and USB TWAIN (32-bit and 64-bit) solution, WIA, Kofax VRS Pro |
|
Pallet weight
|
672.9 lbs |
|
Quantity per pallet
|
15 pc(s) |
|
Cables included
|
USB, AC |
|
Ethernet LAN
|
Yes |
|
Processor frequency
|
1200 MHz |
|
Package dimensions (WxDxH)
|
23.6 x 15.6 x 28.8" |
|
Compatible operating systems
|
Windows 11; Windows 10; Windows 8; Windows 8.1; Windows 7; macOS X 10.10 Yosemite; macOS 10.11 El Capitan; macOS 10.12 Sierra; Linux; UNIX |
|
Minimum system requirements
|
2 GB available hard disk space, OS hardware requirements see http://www.microsoft.com, or 1.3 GB available hard drive space, Internet; OS hardware requirements see http://www.apple.com for more info; For HP Scan: Windows 10, 8.1, 8, 7: 32/64-bit, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer, 2 GHz processor, 1024 x 768 SVGA monitor |
|
Interface
|
USB, 10/100/1000 Ethernet |
|
USB port
|
Yes |
|
Power consumption (typical)
|
22 W |
|
AC input frequency
|
50 Hz |
|
Power consumption (sleep)
|
1.2 W |
|
Storage temperature (T-T)
|
-40 - 60 °C |
|
Operating relative humidity (H-H)
|
15 - 80 % |
|
Windows operating systems supported
|
Windows 7, Windows 8, Windows 8.1, Windows 10, Windows 11 |
|
Mac operating systems supported
|
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, MacOS |
|
Security algorithms
|
SNMPv3, TLS, FIPS 140, HTTPS, IPSec |
