Width
|
12.2" |
|
Depth
|
7.8" |
|
Height
|
7.48" |
|
Weight
|
8.82 lbs |
|
Touchscreen
|
Yes |
|
Built-in processor
|
Yes |
|
Control type
|
Buttons, Touch |
|
Image formats supported
|
BMP, JPEG, PNG, TIFF |
|
Scanner type
|
Sheet-fed scanner |
|
Media types supported
|
Cut Sheet Paper; Printed Paper (Laser and ink); Pre-Punched Paper; Bank Checks; Business Cards; Freight Bills; Carbonless forms; Plastic Carrier sheets for easily damaged documents; Previously stapled media with staple removed; Plastic cards (up to 1.24 mm thickness) |
|
HP segment
|
Business |
|
Pallet dimensions (W x D x H)
|
47.2 x 39.4 x 77.6" |
|
Number of layers per pallet
|
6 pc(s) |
|
Number of cartons per pallet layer
|
12 pc(s) |
|
Duplex scanning
|
Yes |
|
Optical scanning resolution
|
600 x 600 DPI |
|
Power consumption (PowerSave)
|
0.1 W |
|
Scan to
|
E-mail, Network folder, USB |
|
Auto document feeder (ADF) input capacity
|
80 sheets |
|
Color display
|
Yes |
|
Power consumption (off)
|
0.1 W |
|
Harmonized System (HS) code
|
8471608000 |
|
UNSPSC-code
|
43211711 |
|
Maximum scan size
|
8.5 x 122" |
|
Color scanning
|
Yes |
|
Output color depth
|
24 bit |
|
Scan drivers
|
ISIS, ICA, TWAIN, WIA |
|
Scanning media types supported
|
Business Card |
|
Maximum scan area (ADF)
|
8.5 x 122" |
|
Minimum scan area (ADF)
|
2 x 2" |
|
Electromagnetic compatibility
|
CISPR 22:2008 & CISPR 32:2012/EN 55032:2012 - Class B, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024:2010, EN 300 328 V2.1.1 |
|
Daily duty cycle (max)
|
7500 pages |
|
Input color depth
|
24 bit |
|
Scan file formats
|
BMP, JPEG, PDF, PNG, TIFF, TXT |
|
Grayscale levels
|
256 |
|
Auto Document Feeder (ADF) media weight
|
43 - 350 g/m² |
|
Multi feed detection
|
Yes |
|
Sleep mode
|
Yes |
|
Scanning noise level
|
70 dB |
|
Pallet weight (imperial)
|
939 lbs |
|
Recommended operating temperature range (T-T)
|
17.5 - 25 °C |
|
Recommended system requirements
|
macOS Catalina 10.15; macOS Mojave 10.14; macOS High Sierra 10.13; Microsoft Windows 10; 8.1; 7; XP; 32/64-bit; 2008 R2; 2012 R2; 2016; 2019; 2 GB available hard disk space; CD-ROM/DVD drive or Internet connection; USB port; Microsoft Internet Explorer.
macOS Catalina 10.15; macOS Mojave 10.14; macOS High Sierra 10.13; 1 GB available hard disk space; Internet required; USB. |
|
Box contents
|
Power cord; Power Adapter; USB Cable; Scanner Engine; Flyers; Install Guide |
|
Sustainable technologies and materials
|
RoHS-compliant |
|
Recommended humidity operating range
|
30 - 70 % |
|
Compliance certificates
|
CECP, RoHS |
|
Total carbon footprint (kg of CO2e)
|
110 |
|
Light Source
|
LED |
|
Country of Origin
|
China |
|
Certification
|
CISPR 22:2008 & CISPR 32:2012/EN 55032:2012 - Class B, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024:2010, EN 300 328 V2.1.1 |
|
Built-in display
|
Yes |
|
Product color
|
White |
|
Sustainability certificates
|
ENERGY STAR, EPEAT, EPEAT Silver |
|
Sustainability compliance
|
Yes |
|
Sensor type
|
CMOS CIS |
|
Internal memory
|
1024 MB |
|
Power supply type
|
AC |
|
Linux operating systems supported
|
Yes |
|
Display resolution
|
240 x 320 pixels |
|
Package width
|
15.6" |
|
Package depth
|
9.76" |
|
Package height
|
11.9" |
|
Package weight
|
12.3 lbs |
|
Bundled software
|
Win: HP WIA scan driver, HP TWAIN scan driver (32-bit and 64-bit), HP Scan Premium, HP Scanner Tools Utility, OpenText ISIS (Win only) |
|
Pallet weight
|
939.2 lbs |
|
Quantity per pallet
|
72 pc(s) |
|
Cables included
|
USB, AC |
|
Cabling technology
|
10/100/1000Base-T(X) |
|
Ethernet LAN
|
Yes |
|
Processor frequency
|
666 MHz |
|
Compatible operating systems
|
Windows 11; Windows 10; Windows 8.1; Windows 7; macOS 10.13 High Sierra; macOS 10.14 Mojave; macOS 10.15 Catalina; Linux; Citrix |
|
Minimum system requirements
|
macOS Catalina 10.15, macOS Mojave 10.14, macOS High Sierra 10.13, Microsoft Windows 10, 8.1, 7, XP: 32/64-bit, 2008 R2, 2012 R2, 2016, 2019, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Microsoft Internet Explorer |
|
USB version
|
3.2 Gen 1 (3.1 Gen 1) |
|
USB port
|
Yes |
|
Input voltage
|
90 - 264 V |
|
Power consumption (typical)
|
38 W |
|
AC input frequency
|
50/60 Hz |
|
Power consumption (sleep)
|
1.9 W |
|
Ethernet LAN data rates
|
10,100,1000 Mbit/s |
|
Wi-Fi
|
Yes |
|
Wi-Fi standards
|
Wi-Fi 4 (802.11n), 802.11g, 802.11b |
|
Operating temperature (T-T)
|
10 - 35 °C |
|
Storage temperature (T-T)
|
-40 - 60 °C |
|
Operating relative humidity (H-H)
|
15 - 80 % |
|
Display diagonal
|
4.3" |
|
Server operating systems supported
|
Windows Server 2008 R2 |
|
Windows operating systems supported
|
Windows 7, Windows 8, Windows 8.1, Windows 10, Windows 11 |
|
Mac operating systems supported
|
Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, MacOS |
|
Other operating systems supported
|
Linux |
|
Supported network protocols
|
ARP;ICMP; IGMP;UDP;TCP;DHCP;APIPA;DNS;mDNS;LLMNR;WSD;WS-Scan;SNTP;SMB;SNMP;FTP;SFTP;SMTP;HTTP Server Part;HTTPS |
|
Maximum ISO A-series paper size
|
A4 |
