HPE AP22D 1200 Mbit/s White Power over Ethernet (PoE)1

HPE AP22D 1200 Mbit/s White Power over Ethernet (PoE)2

HPE AP22D 1200 Mbit/s White Power over Ethernet (PoE)3

HPE AP22D 1200 Mbit/s White Power over Ethernet (PoE)4

HPE AP22D 1200 Mbit/s White Power over Ethernet (PoE)5

HPE AP22D 1200 Mbit/s White Power over Ethernet (PoE)

HPE AP22D. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1200 Mbit/s. Security algorithms: OWE, WPA2, WPA3. Ethernet LAN data rates: 1000,2500 Mbit/s. Power over Ethernet (PoE). Product color: White. Power consumption (max): 51 W

Manufacturers: Hewlett Packard Enterprise , HPE

SKU: 8807218

Manufacturer part number: S1U78A

$336.00

Qty:

The HPE Networking Instant On Access Points AP22D is the more versatile version of the AP22. It has the same antenna array and spatial streams (2x2:2) but has a 2.5 GbE uplink port and four 1 GbE downlink ports for hardwired devices. The AP22D is great for IP phones or receipt printers in areas that need more Ethernet ports and only one in-room Ethernet port is available.

Overview
Specifications
Contact Us

Products specifications

Attribute name	Attribute value
Width	3.39"
Depth	1.85"
Height	5.91"
Weight	12.7 oz
Antenna Type	Internal
Placement	Desk, Wall
Cable lock slot	Yes
Cable lock slot type	Kensington
Antennas quantity	2
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Maximum data transfer rate (5 GHz)	1200 Mbit/s
MIMO	Yes
DC voltage range	48 V
6 GHz	No
Technical details
Product color	White
Features
2.4 GHz	Yes
5 GHz	Yes
Performance
Maximum data transfer rate	1200 Mbit/s
Networking standards	IEEE 802.11ax, IEEE 802.3at, IEEE 802.3bt
Cabling technology	10/100/1000Base-T(X)
Ports & interfaces
Ethernet LAN (RJ-45) ports	5
USB 2.0 ports quantity	1
DC-in jack	Yes
Power
Power consumption (typical)	50 W
Power consumption (max)	51 W
Network
Ethernet LAN data rates	1000,2500 Mbit/s
Number of users	75 user(s)
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Security
Security algorithms	OWE, WPA2, WPA3
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Yes
Antenna
Antenna direction type	Omni-directional
Antenna gain level (max)	5.4 dBi
