The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.
Products specifications
| Attribute name |
Attribute value |
|
Processor family
|
Intel® Xeon® Gold |
|
Processor manufacturer
|
Intel |
|
Processor model
|
6240Y |
|
Processor boost frequency
|
3.9 GHz |
|
Processor cores
|
18 |
|
Processor cache
|
25 MB |
|
Processor cache type
|
L3 |
|
On-board graphics card
|
No |
|
Supported instruction sets
|
AVX-512 |
|
Memory clock speeds supported by processor
|
2933 MHz |
|
Tcase
|
74 °C |
|
Processor generation
|
2nd Generation Intel® Xeon® Scalable |
|
Processor base frequency
|
2.6 GHz |
|
Intel® vPro™ Platform Eligibility
|
Yes |
|
Discrete graphics card
|
No |
|
Cooler included
|
No |
|
Market segment
|
Server |
|
Intel Turbo Boost Max Technology 3.0
|
No |
|
Intel® Speed Shift Technology
|
Yes |
|
AVX-512 Fused Multiply-Add (FMA) units
|
2 |
|
Intel® Run Sure Technology version
|
Y |
|
Number of UPI links
|
3 |
|
Intel® Volume Management Device (VMD)
|
Yes |
|
Mode-based Execute Control (MBE)
|
Yes |
|
Intel® Optane™ Memory module included
|
Yes |
|
Component for
|
Server/workstation |
|
ECC
|
Yes |
|
Memory channels
|
Hexa-channel |
|
Processor threads
|
36 |
|
Bus type
|
UPI |
|
PCI Express slots version
|
3.0 |
|
Processor codename
|
Cascade Lake |
|
Processor lithography
|
14 nm |
|
Processor operating modes
|
64-bit |
|
Processor series
|
Intel Xeon Gold 6000 Series |
|
Processor socket
|
LGA 3647 (Socket P) |
|
Scalability
|
4S |
|
Stepping
|
B1 |
|
Thermal Design Power (TDP)
|
150 W |
|
Maximum internal memory supported by processor
|
1 TB |
|
Embedded options available
|
No |
|
Enhanced Intel SpeedStep Technology
|
Yes |
|
Execute Disable Bit
|
Yes |
|
Intel 64
|
Yes |
|
Intel Trusted Execution Technology
|
Yes |
|
Intel TSX-NI
|
Yes |
|
Intel Virtualization Technology (VT-x)
|
Yes |
|
Intel VT-x with Extended Page Tables (EPT)
|
Yes |
|
Intel® AES New Instructions (Intel® AES-NI)
|
Yes |
|
Intel® Turbo Boost Technology
|
2.0 |
|
Maximum number of PCI Express lanes
|
48 |
|
Memory types supported by processor
|
DDR4-SDRAM |
