RUCKUS Networks H550 1200 Mbit/s White Power over Ethernet (PoE)

RUCKUS Networks H550. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1200 Mbit/s. Security algorithms: AES, WPA-TKIP, WPA2, Dynamic PSK, OWE, WPA3-Enterprise, WPA3-Personal, WPA-PSK. Power over Ethernet (PoE). Product color: White
SKU: 6489631
Manufacturer part number: 9U1-H550-WW00
MSRP: $595.00
$402.65
RUCKUS H550 Indoor Access Point Features
In hotels, apartment buildings, and other multi-dwelling structures, wireless connectivity can carry a hefty price tag. You need to connect a wide range of wired devices - IPTV set-top boxes, IP phones, networked minibars - IoT devices like smart locks and sensors - while delivering a great wireless experience for guests.

The RUCKUS H550 wall-mounted access point, IoT gateway and Ethernet switch makes it easy to support the most demanding in-room connectivity requirements. It starts with RUCKUS patented Wi-Fi optimization intelligence to deliver the industry's highest-performing wireless connectivity. Combine that with four-ports of Gigabit Ethernet to connect multiple in-room wired devices, without extra cabling and add supports for Zigbee® and Bluetooth® Low Energy, as well as other protocols via optional USB modules. Put it all in a sleek low-profile design that can be discretely installed over a standard electrical outlet.

Deliver the full range of in-room services while dramatically reducing cabling, installation time, and construction costs.
RUCKUS H550 Indoor Access Point Features
In hotels, apartment buildings, and other multi-dwelling structures, wireless connectivity can carry a hefty price tag. You need to connect a wide range of wired devices - IPTV set-top boxes, IP phones, networked minibars - IoT devices like smart locks and sensors - while delivering a great wireless experience for guests.

The RUCKUS H550 wall-mounted access point, IoT gateway and Ethernet switch makes it easy to support the most demanding in-room connectivity requirements. It starts with RUCKUS patented Wi-Fi optimization intelligence to deliver the industry's highest-performing wireless connectivity. Combine that with four-ports of Gigabit Ethernet to connect multiple in-room wired devices, without extra cabling and add supports for Zigbee® and Bluetooth® Low Energy, as well as other protocols via optional USB modules. Put it all in a sleek low-profile design that can be discretely installed over a standard electrical outlet.

Deliver the full range of in-room services while dramatically reducing cabling, installation time, and construction costs.
Products specifications
Attribute nameAttribute value
Width3.52"
Depth7.03"
Height1.15"
Weight9.81 oz
Antenna TypeInternal
PlacementWall
Maximum data transfer rate (2.4 GHz)574 Mbit/s
Maximum data transfer rate (5 GHz)1200 Mbit/s
MIMOYes
MIMO typeMulti User MIMO
Access Control List (ACL)Yes
IPv4 & IPv6 featuresDual stack IPv4/IPv6
Fit AP mode featuresHotspot 2.0
Airtime Fairness (ATF)Yes
6 GHzNo
Technical details
Product colorWhite
Features
2.4 GHzYes
5 GHzYes
Performance
Maximum data transfer rate1200 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ports & interfaces
Ethernet LAN (RJ-45) ports5
USB 2.0 ports quantity1
Network
Number of users512 user(s)
VLAN supportYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)0 - 95 %
Security
Security algorithmsAES, WPA-TKIP, WPA2, Dynamic PSK, OWE, WPA3-Enterprise, WPA3-Personal, WPA-PSK
Power over Ethernet (PoE)
Power over Ethernet (PoE)Yes
Antenna
Antenna gain level (max)1 dBi
*
*
*
